DPA DDK4000 - Drum microphone kit
DPA DDK4000 - Drum microphone kit
Produkt ist zugänlich: 1 pcs
Hautplager
Festnetzladen
30 Tage Rückgaberecht
sicheres Einkaufen
Garantie
Kostenlose Rücksendung
4.694,93 EUR
Produkteigenschaften
Model :
DPA DDK4000
Artikelposition :
SUP_MC5631
Garantie :
2 Jahre
Hersteller :
DPA Microphones
Produktbeschreibung
Details
4099 Instrument Microphone
Capture the sublime, honest sound of the drum kit
DPA’s selection of mics for the drum kit is designed specifically to put the sound engineer in control of the sound. By starting with the clear, true sound of the entire kit, the engineer has the best starting point to shape the sound wanted for the situation. These mics guarantee a natural and precise sound reproduction of the entire kit. The specific mic placements prevent artefacts, bleed and other shadowing effects.
Natural and precise sound reproduction of the entire kit
A clean slate to convey the wanted “mood” to the audience
Specific mic placements prevent artefacts, bleed and other shadowing effects
Picks up the sound like the drummer hears his kit, thus no or minimum EQ is needed
What’s in the box
The DDK4000 Drum Microphone Kit contains the following mics and accessories.
Microphones
- 1 x 2012 Cardioid Microphone
- 2 x 2015 Wide Cardioid Microphone (Stereo Pair)
- 1 x 4055 Kick Drum Microphone
- 3 x 4099 Core Instrument Microphone, Extreme SPL
Accessories
- 3 x MicroDot Cable (CM2218B00)
- 3 x Drum Microphone Clip (DC4099)
- 3 x Adapter for MicroDot to 3-pin XLR (DAD6001)
2012 Compact Cardioid Microphone
An all-around generalist pencil mic that guarantees excellent results on any instrument on a live stage.
- Durable, reinforced construction
- Excellent transient response
- Uniform cardioid directionality
- Outstanding SPL handling
- Natural and precise sound reproduction
The 2012 can be used as an all-around microphone in applications where dynamic microphones are typically used. In fact, as a condenser mic, it has several advantages over its dynamic counterparts:
- It can capture higher frequencies, has an extended frequency range and a flat frequency response – all in a smaller form factor
- It can cope with both high SPLs as well as capture very delicate sounds, so it works well on many different instruments
- It has a far better transient response than any dynamic microphone, which allows it to pick up the most delicate sound with tremendous accuracy
Specifications
- Directional pattern Cardioid
- Principle of operation Pressure gradient
- Cartridge type Pre-polarized condenser
- Frequency response 20 Hz - 20 kHz
- Effective frequency range, ±2 dB, at 30 cm (11.8 in) 40 Hz to 20 kHz
- Sensitivity, nominal, ±2 dB at 1 kHz 8 mV/Pa; -42 dB re. 1 V/Pa
- Equivalent noise level, A-weighted Typ. 20 dB(A) re 20 µPa (max. 22 dB(A))
- Distortion, THD < 1% 148 dB SPL (151 dB SPL peak)
- Dynamic range Typ. 131 dB
- Max. SPL, THD 10% 153 dB SPL (156 dB SPL peak)
- Switchable attenuator, filters etc. -
- Rated output impedance 60 Ω
- Minimum load impedance 2 kΩ
- Cable drive capability 100 m (328 ft)
- Output balance principle Impedance balancing with Active Drive
- Common mode rejection ratio (CMRR) > 60 dB
- Power supply (for full performance) P48 (Phantom Power)
- Current consumption 0.7 mA
- Connector XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
- Color Matte black
- Weight 83 g (2.9 oz)
- Microphone diameter 19 mm (0.75 in)
- Capsule diameter 17 mm (0.67 in)
- Microphone length 94 mm (3.7 in)
- Maximum output voltage, RMS 8.7 V (21 dBu)
- Polarity +V at pin 2 for positive sound pressure
- Temperature range -40°C to 45°C (-40°F to 113°F)
- Relative humidity (RH) Up to 90%
- Sensitivity selection tolerance (at 1 kHz) ±1.5 dB
2015 Compact Wide Cardioid Microphone
A wide cardioid overhead microphone for ambient pick up of a drum kit or other instrument groups. The 2015 can be positioned close to the drum kit (i.e., over the cymbals) and still capture sound evenly across the entire drum kit. This closer position results in stronger signal from the drum kit and therefore less bleed from the stage.
- Durable, reinforced construction
- Uniform wide cardioid directionality
- Spacious sound due to a wide cardioid pick-up pattern
- Natural and precise sound reproduction
- Compact design for unobtrusive placement on stage
Specifications
- Directional pattern Wide cardioid
- Principle of operation Pressure gradient
- Cartridge type Pre-polarized condenser
- Frequency response 20 Hz - 20 kHz
- Effective frequency range, ±2 dB, at 30 cm (11.8 in) 40 Hz to 18 kHz
- Sensitivity, nominal, ±2 dB at 1 kHz 12 mV/Pa; -37.7 dB re. 1 V/Pa
- Equivalent noise level, A-weighted Typ. 18 dB(A) re 20 µPa (max. 20 dB(A))
- Distortion, THD < 1% 147 dB SPL (150 dB SPL peak)
- Dynamic range Typ. 132 dB
- Max. SPL, THD 10% 150 dB SPL (153 dB SPL peak)
- Switchable attenuator, filters etc. -
- Rated output impedance 60 Ω
- Minimum load impedance 2 kΩ
- Cable drive capability 100 m (328 ft)
- Output balance principle Impedance balancing with Active Drive
- Common mode rejection ratio (CMRR) > 60 dB
- Power supply (for full performance) P48 (Phantom Power)
- Current consumption 0.7 mA
- Connector XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
- Color Matte black
- Weight 83 g (2.9 oz)
- Microphone diameter 19 mm (0.75 in)
- Capsule diameter 17 mm (0.67 in)
- Microphone length 94 mm (3.7 in)
- Maximum output voltage, RMS 8.7 V (21 dBu)
- Polarity +V at pin 2 for positive sound pressure
- Temperature range -40°C to 45°C (-40°F to 113°F)
- Relative humidity (RH) Up to 90%
- Sensitivity selection tolerance (at 1 kHz) ±1.5 dB
4055 Kick Drum Microphone
A flexible, professional mic that captures the power and true sound of the kick drum, when placed inside or outside the drum. The 4055 is one of the only kick drum mics that is not sonically pre-tailored to fit a traditional sound in a specific genre. Its low frequency response and dynamics are superb and result in a tight, natural, well-defined sound - the best low-end with detailed mids and highs.
- Picks up the clear, true sound of the kick drum
- Flat frequency response so you can shape the sound your way
- Built tough to withstand rough use on the live stage
- Asymmetric physical design for easy placement inside or outside
Specifications
- Directional pattern Open Cardioid
- Principle of operation Pressure gradient
- Cartridge type Pre-polarized condenser
- Frequency response 20 Hz - 20 kHz
- Effective frequency range ±2 dB, at 20 cm (7.9 in) 40 Hz - 18 kHz with a 6 dB soft boost at 10 kHz
- Sensitivity, nominal, ±2 dB at 1 kHz 2 mV/Pa; -54 dB re. 1 V/Pa
- Equivalent noise level, A-weighted Typ. 27 dB(A) re. 20 µPa (max. 29 dB(A))
- Equivalent noise level, ITU-R BS.468-4 Typ. 39 dB (max. 41 dB)
- Distortion, THD < 1% 156dB SPL RMS, 159 dB SPL peak
- Dynamic range Typ. 132 dB
- Max. SPL, THD 10% 164 dB SPL peak
- Rated output impedance 380 Ω
- Minimum load impedance 2 kΩ
- Cable drive capability 100 m (328 ft)
- Output balance principle Impedance balancing with Active Drive
- Common mode rejection ratio (CMRR) > 55 dB
- Power supply (for full performance) P48 (Phantom Power)
- Current consumption 2.0 mA
- Connector XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
- Color Matte black
- Weight 241 g (8.5 oz)
- Microphone diameter 57 mm (2.24 in)
- Capsule diameter 17 mm (0.67 in)
- Microphone length 132 mm (5.19 in)
- Maximum output voltage, RMS 9.75 V
- Polarity +V at pin 2 for positive sound pressure
- Temperature range -40°C to 45°C (-40°F to 113°F)
- Relative humidity (RH) Up to 90%
The 4099 perfectly captures the booming sounds of drums and percussion instruments. The mic can be easily positioned to fit diverse types of drums and excel on the snare, toms and hi-hats. The flexible gooseneck can be positioned at different angles to allow a variety of sound nuances. The mic is elegant, lightweight, unobtrusive and designed to stay out of the way during performance.
- Handles high SPLs
- Superior gain-before-feedback
- Flexible and easy mounting
- Robust and durable
Specifications
- Directional pattern Supercardioid
- Principle of operation Pressure gradient
- Cartridge type Pre-polarized condenser
- Frequency response 20 Hz - 20 kHz
- Effective frequency range ±2 dB, at 20 cm (7.9 in) 80 Hz - 15 kHz with 2 dB soft boost at 10-12 kHz. Second order low-cut filter at 80 Hz with DAD4099-BC
- Sensitivity, nominal, ±3 dB at 1 kHz 2 mV/Pa; -54 dB re. 1 V/Pa
- Equivalent noise level, A-weighted Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A))
- Distortion, THD < 1% 134 dB SPL RMS, 137 dB SPL peak
- Dynamic range Typ. 109 dB
- Max. SPL, THD 10% 152 dB SPL peak (label color yellow)
- Rated output impedance From MicroDot: 30 - 40 Ω. From DAD4099-BC or DAD6001-BC: 100 Ω
- Cable drive capability Up to 300 m (984 ft) with DAD6001-BC/DAD4099-BC XLR Adapter
- Output balance principle Signal balanced with DAD4099-BC or DAD6001-BC XLR Adapter
- Common mode rejection ratio (CMRR) > 60 dB from 50 Hz to 15 kHz with DAD4099-BC or DAD6001-BC XLR Adapter
- Power supply (for full performance) For wireless systems: Min. 5 V - max. 10 V through DPA adapter
- With DAD6001-BC or DAD4099-BC: P48 (Phantom Power). Will work from 12 V
- Current consumption Typ. 1.5 mA (microphone). 3.5 mA with DAD4099-BC or DAD6001-BC XLR Adapter
- Connector MicroDot
- Color Black
- Weight Microphone: 17 g (0.60 oz)
- Instrument Microphone Clamp Mount (CM4099): 16 g (0.56 oz)
- Instrument Microphone Clip for Accordion (AC4099): 5 g (0.18 oz)
- Instrument Microphone Clip for Bass (BC4099): 20 g (0.71 oz)
- Instrument Microphone Clip for
- Microphone diameter 5.7 mm (0.22 in)
- Microphone length 45 mm (1.8 in)
- Cable length 1.8 m (5.9 ft)
- Cable diameter 1.6 mm (0.06 in) / 2.2 mm (0.09 in)
- Polarity +V at MicroDot pin for positive sound pressure (and pin 2 on DAD4099-BC or DAD6001-BC XLR adapter)
- Temperature range -40°C to 45°C (-40°F to 113°F)
- Relative humidity (RH) Up to 90%
- Gooseneck length 140 mm (5.5 in)
